The UTR-0540 Digital Point Load Test Apparatus is used for determining the strength values of a rock specimen, both in the field and in the laboratory.
Contact us for details
ASTM D5731, ISRM
The UTR-0540 Digital Point Load Test Apparatus is used for determining the strength values of a rock specimen, both in the field and in the laboratory.
Consists of a 70 kN capacity load frame with an upper and lower conical platens, a digital pressure/force manometer and a hydraulic loading cylinder.
A ruler assembled on the frame allows the direct measurement of the distance between the conical platens before and after the test.
The compression load is measured by a pressure transducer connected to an advanced digital easily transportable wooden case.
UTR-0544 Loading platens for compression and indirect/splitting tensile tests on rock specimens should be ordered seperately.
Supplied complete with face protective goggles and carriage box. Loading platens set for compression and indirect/splitting tensile strength test should be ordered separately.
SPECIFICATION
| Dimensions | 280x450x670 mm |
|---|---|
| Weigth (approx.) | 40 kg |
