Features

• Ultra-Sensitive Detection: The Jerome J605 detects hydrogen sulfide (H2S) in air at levels as low as 3 parts per billion (ppb), with a resolution of 20 parts per trillion (ppt), providing highly accurate low-level detection.
• Proven Gold Film Sensor: With over 35 years of field and laboratory validation, the proprietary gold film sensor ensures consistent and repeatable results across a wide range of applications.

• Rugged Construction: The J605 is built to withstand tough environments, housed in a durable, ergonomically designed metal casing that ensures long-lasting performance.
• Extended Battery Life: Enjoy up to 18 hours of battery life per charge, making the J605 reliable and ready for use whenever and wherever needed.
• Advanced Data Logging: Onboard data logging stores up to 20,000 measurements, including date, time, and up to 80 locations, with easy data transfer via USB and SCADA interface capabilities through 4-20 mA output.
• Versatile Application: Ideal for regulatory compliance, odor control at wastewater and landfill facilities, scrubber efficiency testing, and corrosion monitoring in control rooms, with a detection range of 3 ppb to 10 ppm.
• Survey Mode: Continuously draw in air samples to sweep an area for hydrogen sulfide hot spots, enabling targeted corrective actions.
• Field Regeneration: The J605 allows for battery-powered sensor regeneration in the field, extending testing capabilities without the need for downtime.
• Intuitive Interface: Simple, menu-driven operation with easy-to-understand diagnostics and error detection, plus a USB interface for straightforward data transfer.

Why Choose the Jerome J605 Hydrogen Sulfide Analyzer?

Jerome® J605 combines ultra-sensitive detection with rugged portability, making it the ideal choice for industries requiring precise H₂S monitoring in challenging environments. Whether you’re managing odor control, ensuring regulatory compliance, or protecting critical infrastructure, the J605 delivers reliable performance when you need it most.

Applications

• Regulatory Compliance and Permitting:
  Ensure adherence to environmental regulations with accurate H₂S monitoring.
• Nuisance Odor Monitoring:
  Monitor and control odor emissions in wastewater treatment and landfill management.
• Scrubber/Biofilter Efficiency Testing:
  Evaluate the performance of scrubbers and biofilters in removing H₂S from air streams.
• Semi-Conductor Manufacturing:
  Monitor H₂S levels in cleanroom environments to prevent corrosion and contamination.

• Control Room Corrosion Monitoring:
  Protect sensitive electronics and equipment from corrosive H₂S gases in control rooms.
• Agriculture and Livestock Production:
  Manage H₂S emissions from manure storage and treatment facilities.
• Geothermal Emissions Monitoring:
  Monitor and control hydrogen sulfide emissions from geothermal power generation.

Specifications

• Detection Range:
  • 3 ppb (0.003 ppm) – 10 ppm
• Resolution:
  • 20 ppt (0.02 ppb) *range dependent
• Response Time:
  • Survey Mode: 12-27 seconds
  • Manual Mode: 12-27 seconds
  • Auto Mode: 12-53 seconds
• Flow Rate:
  • 150 mL/min
• Result Units:
  • ppm, ppb
• Autosample Intervals:
  • 1, 2, 5, 10, 15, 30, 45, 60, 90, or 120 minutes
• Integrated Data Storage:
  • Stores up to 20,000 test results, retaining date, time, and up to 80 locations
• Display:
  • 3.5” (9 cm) backlit LCD
• Battery:
  • Rechargeable NiMH with 18-hour life; charges in 3 hours
• Power Requirements:
  • 12 VDC for the instrument
  • 100-240 VAC, 47-63 Hz, 1.3A for the AC power supply
• Fuse:
  • Auto-resetting fuse
• Operating Environment:
  • 0°C to 40°C, non-condensing, non-explosive
• Output:
  • Digital: USB serial data to PC, printer, or USB flash drive
  • Analog: 4-20 mA passive current loop; accurate to 0.3% of output
• Dimensions:
  • 11” L x 6” W x 6.5” H
  • (28 cm L x 16 cm W x 17 cm H)
• Weight:
  • 5.4 lbs. (2.5 kg)
• Warranty:
  • 1 year, factory parts and labor
• Certifications:
  • TUV 61010, CE

Related Accessories

• Battery Pack Assembly: Keep your instrument powered for extended use with this reliable battery pack.
• Scrubber Filter, LFS: Essential for maintaining clean airflow and removing contaminants.
• Scrubber Filter, LFD: Additional filtration for enhanced air purity and accurate readings.
• Ammonia Filter: Protects the instrument from ammonia interference during measurements.
• External Battery Pack: Provides additional power for prolonged field operations.
• Hard-Sided Carrying Case: Durable protection for your instrument during transport.
• Soft-Sided Carrying Case: Lightweight and flexible option for easy transport.
• 10:1 Dilution Module: Allows precise dilution of samples for more accurate measurements.
• Probe: High-quality probe designed for accurate sample collection and measurement.
• Pack of 20 Fritware, .25 cm Diameter: Replacement fritware for maintaining sample integrity.
• Acrodisc Filter, 25 mm: Ensures high-quality filtration during sample collection.
• AC Power Supply/Charger: Reliable power source to keep your instrument charged and ready for use.
• Line Cord, 115 VAC: Standard power cord for connecting your instrument to a power source.
• Accessory Kit: Comprehensive kit including all essential accessories for optimal instrument operation.
• Maintenance Kit: Keep your instrument in top condition with this essential maintenance kit.
• Intake Kit: Complete setup for precise sample intake and analysis.

• Jerome® Functional Test Module, 250 ppb, 115V: Validates the accuracy of your instrument with a 250 ppb test module.
• Jerome® Functional Test Module, 30 ppb, 115V: Ensures the reliability of your instrument with a 30 ppb test module.
• Zero Air Filter: Removes impurities from the air to ensure accurate measurements.
• Scrubber Filter: Additional filtration to maintain the purity of samples.
• Chlorine Filter: Specifically designed to remove chlorine from samples to prevent interference.
