Features and Benefits

• Ultra-Sensitive Detection: The Jerome® 631-X detects hydrogen sulfide (H2S) in air at levels as low as 3 parts per billion (ppb), with a detection range of 0.003 ppm to 50 ppm. This makes it ideal for regulatory compliance, odor control monitoring, scrubber efficiency testing, and corrosion monitoring in control rooms.
• Proven Gold Film Sensor: The proprietary gold film sensing technology has been validated both in the laboratory and the field for over 35 years, ensuring repeatable and reliable results across a wide range of applications.
• Rugged Construction: Built with a sturdy metal housing, the 631-X is designed to withstand tough environments, providing durability and reliable performance whether in the lab or in the field.
• Easy Operation: The 631-X is simple to use, offering accurate hydrogen sulfide readings at the touch of a button. The quick reference guide beneath the handle and the easy-to-read display with automatic backlight make day-to-day operation straightforward, even in low-light conditions.
• Survey Mode: Continuously draw in air samples to sweep an area for hydrogen sulfide hot spots, enabling quick identification and corrective action.
• Optional Data Logging: The 631-X can be equipped with a data logger module capable of storing up to 1,000 measurements, including date and time, for easy tracking and analysis.
• Optional Autosample Mode: Program the 631-X to take samples at intervals ranging from 1 to 60 minutes, allowing for continuous monitoring without manual intervention.
• Field Regeneration: Extend testing capabilities on-location with the option to perform sensor regeneration in the field using the Power Inverter Kit, ensuring the instrument is always ready for use.

Why Choose the Jerome X631 Hydrogen Sulfide Analyzer

Jerome® 631-X is a durable, dependable, and easy-to-use analyzer that delivers accurate low-level H₂S detection in seconds. Whether you’re working in regulatory compliance, industrial safety, or odor control, the 631-X provides the reliability and precision you need in both field and lab environments.

Applications

• Regulatory Compliance and Permitting:
  Ensure adherence to environmental regulations with precise H₂S monitoring.
• Nuisance Odor Monitoring:
  Monitor and manage odor emissions in wastewater treatment and landfill management.
• Scrubber/Biofilter Efficiency Testing:
  Assess the performance of scrubbers and biofilters in removing H₂S from air streams.
• Semiconductor Manufacturing:
  Prevent corrosion and contamination by monitoring H₂S levels in cleanroom environments.
• Control Room Corrosion Monitoring:
  Protect sensitive electronics and equipment from corrosive H₂S gases in control rooms.
• Agriculture and Livestock Production:
  Manage H₂S emissions from manure storage and treatment facilities.
• Geothermal Emissions Monitoring:
  Monitor and control hydrogen sulfide emissions from geothermal power generation.
• Paper Production:
  Ensure safe and compliant operation in pulp and paper processing facilities by monitoring H₂S levels.

Specifications

• Detection Range:
  • 0.003 ppm to 50 ppm
• Resolution:
  • 0.001 ppm *range dependent
• Accuracy:
  • ±0.003 ppm at 0.05 ppm
  • ±0.03 ppm at 0.5 ppm
  • ±0.3 ppm at 5 ppm
  • ±2 ppm at 25 ppm
• Response Time
  • Survey Mode: 3-20 seconds
  • Sample Mode: 12-30 seconds
• Flow Rate:
  • 150 ± 10 mL/min
• Result Units:
  • ppm
• Optional Integrated Data Storage::
  • Stores up to 1,000 test results, retaining date and time
• Optional Autosample Mode:
  • Programmable intervals between 1 and 60 minutes
• Display:
  • Backlit LCD
• Battery:
  • Rechargeable NiCad- Battery Life: 6 hours-Charging Time: 14 hours
• Power Requirements:
  • 100-120 VAC, 50/60 Hz, 1A
  • 220-240 VAC, 50/60 Hz, 1A
• Fuse::
  • F1A 250 V, 5 mm x 20 mm
• Operating Environment:
  •  0°C to 40°C, non-condensing, non-explosive
• Output:
  • RS-232 Serial Port
  • Analog: 4-20 mA passive current loop
• Dimensions:
  • Standard: 13” L x 6” W x 4” H (33 cm L x 15 cm W x 10 cm H)
  • XE Model: 14” L x 7” W x 7” H (35 cm L x 18 cm W x 18 cm H)
• Weight:
  • Standard: 7 lbs. (3.18 kg)
  • XE Model: 8 lbs. (3.5 kg)
• Warranty:
  • 1 year, factory parts and labor
• Certifications:
  • CE (220-240 VAC, 631-XE model only)

Accessories and Parts

• Ammonia Filter: Protects the instrument from ammonia interference during measurements.
• 10:1 Dilution Model: Allows for precise dilution of samples for more accurate measurements.
• Soft-Sided Field Carrying Case: Lightweight and flexible option for safe and easy transport of your instrument.
• Probe: High-quality probe designed for accurate sample collection and measurement.
• Trimmer Tool: Essential tool for precise adjustments and maintenance.
• Pack of 20 Fritware, .25 cm Diameter: Replacement fritware for maintaining the integrity of sample collection.
• Cable Assembly, JCI/JCS Interface: Ensures seamless connectivity between the instrument and interface systems.
• Line Cord, 115 VAC: Standard power cord for connecting your instrument to a power source.

• Data Logger: Enables data storage and logging for up to 1,000 measurements, essential for tracking and analysis.
• Tube Nut: Replacement part for secure and reliable connections within the instrument setup.
• Hard-Sided Carrying Case Assembly: Durable protection for your instrument during transport and storage.
• Accessory Kit: Comprehensive set of tools and accessories for optimal instrument operation.
• Maintenance Kit: Keep your instrument in top condition with this essential maintenance kit.
• Jerome Communication Software Kit (Windows 7/8): Facilitates communication and data management via a Windows-compatible interface.
• Jerome Communication Software Data Logger Kit (Windows 7/8): Combines communication and data logging capabilities for enhanced instrument functionality.
• Straight Intake Kit: Complete intake setup for precise sample collection and analysis.
• Jerome® Functional Test Module, 250 ppb, 115V: Validates the accuracy of your instrument with a 250 ppb test module.
• Jerome® Functional Test Module, 30 ppb, 115V: Ensures the reliability of your instrument with a 30 ppb test module.
• Zero Air Filter: Removes impurities from the air to ensure accurate measurements.
• Scrubber Filters:
  • Standard Scrubber Filter: Maintains clean airflow for accurate measurements.
  • LFS Scrubber Filter: Provides additional filtration for enhanced air purity.
  • LFD Scrubber Filter: Advanced filtration option for maintaining sample integrity.
• Chlorine Filter: Specifically designed to remove chlorine from samples to prevent interference.
• Battery Pack Assembly X431/X631: Reliable power source for extended instrument operation.
